Electronic Delivery Bed, 4 Motors
Overview
- Delivery Bed, Metal parts coated with zinc phosphate and varnished with electrostatic epoxy polyester powder
- Easily cleanable, 3 sectional compact laminate mattress surface.
- X-Ray permeable lying surface
- Converting to Bed
- Headboard and footboard made of hygienic PP materials
- Side rails made of hygienic PP materials
- IV pole inserts and protective bumpers on the two corners of headboard
- IV pole and drainage hook
- Stainless steel accessory rail
- 125 mm diameter swivel castors with central locking system and directional lock
- Electronic adjustments of backrest, legrest, height-up &down positions
- Electrical operated Trendelenburg and Reverse Trendelenburg positions
- Hand control unit
- Electronically CPR (Reset)
- Equipped with powerful column motors Linak brand
- Two-piece ABS plastic covered lower chassis
- Chrome-Nickel coated accessories against corrosion
- Easily removable stainless steel waste bowl
- Adjustable patient handles
- Sliding foot section mechanism
- Angle indicators on the side rails
- Back up battery for non-stop operation in case of power failure
- Mattress with 12 cm thickness suitable for lying surface with antibacterial & flame retardant cover
- Adjustable Leg supports
- Squatting Bar
- Heel Supports (foot support)
- Manual CPR for backrest with 2 sides lever
Description
Technical Details
Backrest Angle | 0°-67° |
Legrest Angle | 0°-27° |
Trendelenburg Angle | 0°-20° |
Reverse Trendelenburg Angle | 0°-20° |
External Dimensions | 109×209 cm |
Bed Surface (Extended) | 85×191 cm |
Bed Surface (Retracted) | 85×144 cm |
Height (Without Mattress) | 60-100 cm |
Mattress Thickness (Backrest and Pelvic Sections) | 12 cm |
Safe Working Load Capacity | 250 kg |
Weight | 140 kg |
Electrical Data
Power In | Max. 3,15A 100V – 240V ~ 50/60 Hz |
Electrical Shock Protection | Class I, Type B |
Liquid Ingress Protection | IPX6 |
Battery | 2x 12V Series Connected, sealed, rechargeable, Lead / Acid gel, 1.2 amp hrs |
